The LED engines with our latest technologies have integrated LED mod-ule, optical lens, heatsink, and/or other optional accessories like mag-nets, wires, plug and receptacle. The LED engines include CUBE and DISC shape, which are specialized for the application of surface mounted fix-tures. It offers from 800 lumens up to 4000 lumens, which are suitable for the fixture with a light-emitting surface from 4” to 24”.

Besides the basic features like phase (TRIAC & ELV) dimmable, flick-er-free, excellent colour consistency, 50k hours lifespan, and higher system reliability, we also provide CCT adjustable versions with various control methods.

• 2.0G: Regular 1-CCT LED engines.

• 2.1G: LED engines of 3-Step CCT adjustment via a slider switch on board.

• 2.2G: LED engines of 3-Step CCT adjustment via a remote CCT switch.

• 2.3G: LED engines of 3-Step CCT adjustment via a switch on the wall.

• 2.4G: LED engines of Dim-to-Warm via a phase dimmer.

In compliance with CEC Appendix JA8 Qualification Requirements for High Efficacy Light Sources of Title 24.

In compliance with ENERGY STAR Program Requirements for Lamps & Program Requirements for Luminaires.

Perfectly in compliance with phase (TRIAC & ELV) dimmers of popular brands on the market.

Excellent colour consistency of 3 steps SDCM.

2.5KV transient line voltage surge protection, OVP, and OTP.

Quick push-in connector to simplify installation and reassembly.

Optional accessories like magnets, wires, plug, and receptacle are available.

Various CCT adjustable versions are provided..

5-Years limited warranty.
